| Title | ASME Y14.5 |
| Organization | American Society of Mechanical Engineers |
| Committee | ASME Y14 Committee |
| Status | Active |
| Latest version | 2018 |
| Related standards | ASME Y14.1, ASME Y14.2, ASME Y14.100, ISO 1101, ISO 286 |
| Field | Engineering drawing, Geometric dimensioning and tolerancing |
ASME Y14.5. It is the definitive national standard in the United States for the language of Geometric dimensioning and tolerancing (GD&T). Published by the American Society of Mechanical Engineers, the standard establishes uniform practices for stating and interpreting dimensions, tolerances, and related requirements on engineering drawings and in related documents. Its principles are critical for ensuring the interchangeability and functional performance of manufactured parts across industries like aerospace, automotive, and medical device manufacturing.
The development of modern dimensioning practices can be traced to the work of early 20th-century industries, including the United States Army Air Corps and major automotive manufacturers like General Motors. The first formal American standard, published by the American Standards Association, was released in 1966. The American Society of Mechanical Engineers assumed responsibility for the standard, with the influential 1982 version solidifying many core GD&T concepts. Subsequent revisions in 1994, 2009, and 2018 have refined the symbology, introduced new concepts like composite tolerancing, and aligned more closely with global standards from the International Organization for Standardization. The ASME Y14 Committee oversees its ongoing maintenance and development.
The standard is built upon the foundational rule that all dimensions and tolerances apply in a free state unless otherwise specified. It emphasizes the datum reference frame, a theoretically exact coordinate system established from datum features on a part. Key principles include the envelope principle, which defines the limits of a feature of size, and the concept of maximum material condition and least material condition, which are essential for functional gage design. These rules ensure that drawings clearly communicate design intent for manufacturing and quality control processes, preventing ambiguity that could arise from traditional coordinate dimensioning.
ASME Y14.5 defines a comprehensive set of symbols used in feature control frames to specify geometric tolerances. These include symbols for form controls like straightness and flatness, and profile controls such as profile of a line. The standard also provides symbols for datums, like the datum feature symbol, and modifiers including maximum material condition, least material condition, and regardless of feature size. These symbols, when applied within the structured syntax of a feature control frame, provide a precise and compact method for defining allowable geometric variation on engineering drawings, replacing lengthy notes.
The standard categorizes geometric tolerances into several types of characteristics. Form controls, such as circularity and cylindricity, regulate the shape of individual features. Orientation controls, including parallelism, perpendicularity, and angularity, govern the relationship of features to specified datums. Location controls, principally position tolerance, are crucial for specifying the allowable deviation for features like holes. Runout controls, circular runout and total runout, are used to control the variation of surfaces during rotation. Finally, profile controls, profile of a surface and profile of a line, are versatile tools for defining the allowable error for complex contoured features.
ASME Y14.5 is part of a larger family of standards developed by the ASME Y14 Committee. These include ASME Y14.1 for drawing sheet size and format, ASME Y14.2 for line conventions and lettering, and ASME Y14.100 which establishes overarching practices for engineering drawings. The International Organization for Standardization publishes analogous standards, primarily ISO 1101 for geometric tolerancing and ISO 286 for limits and fits. While harmonization efforts continue, differences remain between the ASME and ISO systems. The standard's principles are also embedded in numerous computer-aided design software packages and form the basis for training and certification programs from organizations like the American Society for Quality. Category:American Society of Mechanical Engineers Category:Engineering drawing Category:Technical standards
